IF03RSF
Discontinued Product
3" Dim To Warm Round Super Shallow 4" Deep Ic Rated - 1057Lm
Versatile super shallow plenum 3" round recessed LED luminaire with a 4" deep IC housing, featuring downlight, adjustable accent, wall wash and pinhole downlight trim options with insulated ceiling housing. Two-stage optical system for smooth low glare light distribution. Zhaga International Standard LED module for ease of maintenance and replacement. Shallow plenum design. Tool-less LED module, driver, and J-Box access. Multi-Bar mounting brackets. Expandable bar hangers with horizontal range of 14.2"-26", and vertical adjustment of 2.325". Posi-lock trim retention springs. Integral 0.625" collar, works with up to 1" ceiling. For thicker ceilings consult factory.
Resources
Families
- Infinium
Trim Type
- Adjustable
- Flange
- Pinhole
- Wall Wash
Lumens
- 502 Lm
- 647 Lm
- 1057 Lm
Distribution
- Medium
- Narrow
- Very Narrow
- Wide
Shape
- Round
Aperture
- 3 In.
Installation Type
- New Construction
Dimming Protocol
- 0-10 V
- ELV
- MLV
Dynamic LED Color
- Dim to Warm
Static LED Color
- Full Spectrum
Ratings & Compliance
- Buy America
- Buy American Act (BAA)
- Chicago Plenum
- IC
- Made in America
- Wet
Lamp Source
- LED
Watts
- 7.3 w
- 9.3 w
- 15.2 w
Circuit
- Single Circuit
Efficacy
- 69 lm/w
- 70 lm/w
Listings
- ETL
- UL
Materials
- Aluminum
- Steel
Trim Finish
- Black
- Matte White
Warranty
- 5 yr
Voltage
- 120 V
- 277 V
Dimming Range
- 1%
