IF03RMF

Discontinued Product

3" Dim To Warm Round Downlight - 1321Lm

Versatile shallow plenum 3" round recessed LED luminaire features downlight, adjustable accent, wall wash and pinhole downlight trim options with new construction, insulated ceiling and retrofit housings. Two-stage optical system for smooth low glare light distribution. Zhaga International Standard LED module for ease of maintenance and replacement. Shallow plenum design. Tool-less LED module, driver, and J-Box access. Multi-Bar mounting brackets. Expandable bar hangers with horizontal range of 14.2"-26", and vertical adjustment of 1.75" for Non-IC housing and 2.325" for IC housings. Posi-lock trim retention springs. Integral 0.625" collar, works with up to 1" ceiling. For thicker ceilings consult factory.

Resources

Families

  • Infinium

Trim Type

  • Adjustable
  • Downlight
  • Flange
  • Lensed
  • Pinhole
  • Wall Wash

Lumens

  • 502 Lm
  • 647 Lm
  • 1057 Lm
  • 1321 Lm

Distribution

  • Medium
  • Narrow
  • Very Narrow
  • Wide

Shape

  • Round

Aperture

  • 3 In.

Installation Type

  • New Construction
  • Retrofit & Remodel

Emergency Options

  • Integral EM Battery

Dimming Protocol

  • 0-10 V
  • ELV
  • MLV

Dynamic LED Color

  • Dim to Warm

Static LED Color

  • Full Spectrum

Ratings & Compliance

  • Buy America
  • Buy American Act (BAA)
  • Chicago Plenum
  • IC
  • JA8
  • Made in America
  • Non-IC
  • Wet

Lamp Source

  • LED

Watts

  • 9.3 w
  • 11.3 w
  • 17.2 w
  • 21.7 w

Circuit

  • Single Circuit

Efficacy

  • 54 lm/w
  • 57 lm/w
  • 61 lm/w

Listings

  • ETL
  • UL

Materials

  • Aluminum
  • Steel

Trim Finish

  • Black
  • Matte White

Warranty

  • 5 yr

Voltage

  • 120 V
  • 277 V

Dimming Range

  • 1%

Inspiration


Infinium Collection
