RC2009FTLEDGV
RC2009FTLEDGV.DWNG.pngRC2009FTLEDGV
2' x 2' New Construction - 24000Lm
Recessed square high lumen 2' x 2' fixture for high ceiling area lighting. Designed for recessed dry wall ceiling installation. May be installed from above or below ceiling. Fixture is available from 11000-24000 lumens. Produces even glare free illumination. Lens is mechanically attached to trim.
Resources
Families
- Infinium
Trim Type
- Flange
Lumens
- 11000 Lm
- 15000 Lm
- 22000 Lm
- 24000 Lm
Shape
- Square
Aperture
- 24 In.
Installation Type
- New Construction
Dimming Protocol
- 0-10 V
- DALI
- ELV
- MLV
Ratings & Compliance
- Buy American Act (BAA)
- Made in America
- Non-IC
Lamp Source
- LED
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 85 CRI
Color / Finish
- Bronze
- Custom
- Matte Black
- Matte White
Watts
- 88 w
- 117 w
- 174 w
- 188 w
Efficacy
- 92.0 lm/w
- 92.8 lm/w
- 96.7 lm/w
Listings
- ETL
- UL
Materials
- Aluminum
Warranty
- 5 yr
Voltage
- 120 V
- 277 V
Dimming Range
- 1%
- 10%
- Non-Dimmable
