SR2DMO, SR2DMI, SR2DMR
SS2D - NC.DWNG.png
SS2D - IC.DWNG.png
SS2D - RT.DWNG.pngSR2DMO, SR2DMI, SR2DMR
2" Xt Square Deep Downlight - 2000Lm
Precision Die-formed 20 gauge galvanized steel housing and integral junction box with (1) 7/8" knockout for Non-IC (not designed for through branch circuit wiring) and (1) 5/8", (3) 7/8" and 2 (1") knockouts for IC. Junction box capacity: 8 12AWG rated for 90 °C. Tool-less driver and junction box access for ease of maintenance. Posi-loc trim rentention springs for 5/8"-1" ceiling thickness. For thicker ceilings consult factory.
Resources
Families
- A Spec
Trim Type
- Downlight
- Flange
Lumens
- 1000 Lm
- 1300 Lm
- 2000 Lm
Distribution
- Medium
- Very Narrow
- Wide
Shape
- Square
Aperture
- 2 In.
Installation Type
- New Construction
- Retrofit & Remodel
Emergency Options
- Remote EM Battery
Dimming Protocol
- 0-10 V
- ELV
- MLV
Ratings & Compliance
- Buy American Act (BAA)
- Chicago Plenum
- IC
- Made in America
- Non-IC
Lamp Source
- LED
CCT
- 2700K
- 3000K
- 3500K
- 4000K
CRI
- 83 CRI
- 98 CRI
Watts
- 11.1 w
- 15.0 w
- 23.7 w
Efficacy
- 44 lm/w
- 45 lm/w
- 45 lm/w
Listings
- ETL
- UL
Materials
- Aluminum
- Steel
Trim Finish
- Black
- Matte White
Warranty
- 5 yr
Voltage
- 120 V
- 277 V
Dimming Range
- 10%
- Non-Dimmable
