IF03SSF

Discontinued Product

3" Pc Super Shallow 4" Deep IC Rated - 700Lm

Versatile super shallow plenum 3" square recessed LED luminaire with a 4" deep IC housing, featuring downlight, adjustable accent, wall wash and pinhole downlight trim options with insulated ceiling housing. Two-stage optical system for smooth low glare light distribution. Zhaga International Standard LED module for ease of maintenance and replacement. Shallow plenum design. Tool-less LED module, driver, and J-Box access. Multi-Bar mounting brackets. Expandable bar hangers with horizontal range of 14.2"-26", and vertical adjustment of 2.325". Posi-lock trim retention springs. Integral 0.625" collar, works with up to 1" ceiling. For thicker ceilings consult factory.

Resources

Families

  • Infinium

Trim Type

  • Adjustable
  • Flange
  • Pinhole
  • Wall Wash

Lumens

  • 359 Lm
  • 503 Lm
  • 700 Lm

Distribution

  • Medium
  • Narrow
  • Very Narrow
  • Wide

Shape

  • Square

Aperture

  • 3 In.

Installation Type

  • New Construction
  • Retrofit & Remodel

Dimming Protocol

  • 0-10 V
  • ELV
  • MLV

Static LED Color

  • Full Spectrum

Ratings & Compliance

  • Buy America
  • Buy American Act (BAA)
  • Chicago Plenum
  • IC
  • Made in America
  • Wet

Lamp Source

  • LED

CCT

  • 2200K
  • 2700K
  • 3000K
  • 3500K
  • 4000K

Watts

  • 5 w
  • 7 w
  • 10 w

Circuit

  • Single Circuit

Efficacy

  • 66 lm/w
  • 69 lm/w

Listings

  • ETL
  • UL

Materials

  • Aluminum
  • Steel

Trim Finish

  • Black
  • Matte White

Warranty

  • 5 yr

Voltage

  • 120 V
  • 120-277 V
  • 277 V

Dimming Range

  • 1%
  • Non-Dimmable
