16" Low/Mid Bay
PA1611LX.DWNG.png16" Low/Mid Bay
14100 Lm - Dual Refractor System
PA1611LXÂ
16" prismatic pendant series is a performance luminaire that provides excellent vertical surface illumination. Prismatic refractor provides horizontal and vertical distribution. PA1611LX dual refractor optical system for enhanced indirect lighting. Single mid-powered LED modules produce up to 13000 source lumens. A wide variety of mounting options. LED module and driver are serviceable for future replacement and maintenance. Emergency battery backup available.Â
16" prismatic pendant series is a performance luminaire that provides excellent vertical surface illumination. Prismatic refractor provides horizontal and vertical distribution. PA1611LX dual refractor optical system for enhanced indirect lighting. Single mid-powered LED modules produce up to 13000 source lumens. A wide variety of mounting options. LED module and driver are serviceable for future replacement and maintenance. Emergency battery backup available.Â
Resources
PA1611LX, PA, PA1611
Families
- Low Bay
- Mid Bay
Lumens
- 6500 Lm
- 10000 Lm
- 13000 Lm
Diameter
- 16 In.
Emergency Options
- Remote EM Battery
Ratings & Compliance
- Buy American Act (BAA)
- Made in America
Lamp Source
- LED
CCT
- 2700K
- 3000K
- 3500K
- 4000K
CRI
- 80 CRI
Color / Finish
- Bronze
- Custom
- Gloss Black
- Matte Black
- Matte White
- Silver
Watts
- 54.1 w
- 81.1 w
- 103.9 w
Efficacy
- 113 lm/w
- 114 lm/w
- 117 lm/w
Listings
- ETL
- UL
Materials
- Aluminum
- Polycarbonate
Warranty
- 5 yr
Voltage
- 120-277 V
- 347 V
